Set of Muting Arms, L-Logic (Exit Only), 2 Parallel Beams
1390804
Parallel beams Muting arms with 2 retro-reflective sensors
Can be used in conjunction with Safegate access control barriers to create a one-way access control system with exit-only L-Muting logic
What's in the box: 2 Muting arms (active and passive elements) with pre-wired and pre-aligned Muting sensors, screws and fixing brackets
| Max. range (m) | 3.5 |
| Functioning system | TRX (Transceiver) |
| Operating temperature (°C) | - 30 ... 55 |
| Muting logic | L (One way) logic with 2 parallel beams |
| Muting sensor field | Adjustable height and tilting |
| Characteristic output of Muting sensors | PNP 100 mA at 24 VDC |
| Muting sensors | 2 optoelectronic for glass application, built-in, pre-aligned and pre-wired with parallel beams |
| Integrated optoelectronic sensors | 2 with parallel beams |
| Detection | Access control |
| Protective enclosures | None |
| Packaging dimensions HxLxW (mm) | 145 x 430 x 200 |
| Product class | C |
| Custom tariff | 85389099 |
| Fastening | Back slot, side slot with set of LL type brackets (included). SFB SG swivel brackets (optional) |
| Gross weight (g) | 1873,86 |
